REMORPH DESIGN

1000mm/s travel speed

125.000mm/s² max accels

Long meltzone hotends

LGX PRO or same kind

BEACON or other z sensors

CPAP for print cooling and chamber convection

MAGBED, from provok3d aka boxxy
Note: alternative buildplate is possible

HEPA and carbon pellets with top-down convection

Static core XY

Frame made of 3030s and 2020s T-slot extrusions

Nearly all mechanical parts are machined aluminum

48V N23 BLDC servos for X and Y

Isolated servos and electronics

9mm belts for X Y Z

12mm linear rails

5:1 gear ratio for Z

Maxwell kinematic couplers

X307 Y307 Z304mm

W460 D560 H720mm

Hinges, door handle and connected cables are all internal

4mm panels

Sealed internal filament dry box

External filament feed possible

Optical endstops

All idlers and gears use 5mm shafts with 13mm bearings

Nozzle wiper with a slide-out bucket
